System Map: Front View with LCD Panel Open (Model A)
4
6
3
5
7
1
Note that the Touchpad
and Buttons valid opera-
tional area is that indicat-
ed within the red dotted
lines above.
8
6
3
5
7
1
8
Design I
Design II
14” (35.56cm)
2 2
8
Figure 2
Front View with LCD Panel Open
(Model A)
1. PC Camera (Optional)
2. LCD
3. Power Button
4. Hot-Key Buttons (Designs I & III
Only)
5. LED Status Indicators
6. Keyboard
7. Built-In Microphone
8. Touchpad & Buttons
14” (35.56cm)
4
6
3
5
7
1
8
Design III
2
14” (35.56cm)

Wireless Device
Operation Aboard Aircraft
The use of any portable electronic transmission de-
vices aboard aircraft is usually prohibited. Make sure
the wireless modules are OFF if you are using the
computer aboard aircraft.
Use the key combinations to toggle power to the
3.75G/HSPA/WLAN/Bluetooth modules, and check
the LED indicator/visual indicator to see if the mod-
ules are powered on or not (see
Table 6 on page 11 ).
