14
Engli
sh
System Map: Front, Left, Right, Rear & Bottom Views (Model C)
Figure 7- Front, Left, Right, Rear & Bottom Views (Model C)
1. LED Power Indicators
2. DC-In Jack
3. External Monitor Port
4. RJ-45 LAN Jack
5. HDMI-Out Port
6. 3 * USB 2.0 Ports
7. Vent
8. Multi-in-1 Card Reader
9. Microphone-In Jack 10. Headphone-Out Jack
11. Optical Device Drive Bay
12. Emergency Eject Hole
13. Security Lock Slot
14. Battery
15. Component Bay Cover
16. Hard Disk Bay Cover
17. Speakers
17
7
Bottom
7
2
1
7
6
4
6 3
Left
Right
5
Front
Rear
10
12 13
11
8
14
15
7
7 9
14
17
7
16 6
7

Overheating
To prevent your computer from overheating make sure
nothing blocks any vent while the computer is in use.
CPU
The CPU is not a user serviceable part. Accessing the
CPU in any way may violate your warranty.
