System Map: Left & Right Views
Figure 1 - 5
Left & Right Views
1. DC-In Jack
2. RJ-45 LAN Jack
3. External Monitor
Port
4. Mini-IEEE 1394
Port
5. Vent/Fan Intake/
Outlet
6. 3 * USB 2.0 Ports
7. Optical Device
Drive Bay (for CD/
DVD Device - see
page
2 - 3 )
8. RJ-11 Phone Jack
9. Security Lock Slot
1
5
2
4
7
9 8
3
6
6
Overheating
To prevent your computer from overheating make sure nothing blocks the vent(s)/fan in-
take(s) while the computer is in use.
