Windows XP Information
D - 44 Bluetooth Module
D
5. Use the Fn + F12 key combination to turn on the Bluetooth module.
6. Run the IVT Corporation BlueSoleil program from the desktop icon or Start menu.
7. The connection status will then be displayed.
Figure D - 9 - Bluetooth Connected
8. To disconnect click File from the IVT Corporation BlueSoleil - Main Window, and select Exit (the Local Area
Connection will then display “A network cable is unplugged”).
9. Do not use the close button or Fn + F12 key combination before clicking File > Exit or the correct status will
not be displayed.
10. You can then use the Fn + F12 key combination to turn off the Bluetooth module (check the LED icon for the
Bluetooth module power status).
Figure D - 10 - Bluetooth Disconnected
