Windows XP Information
3.5G Module D - 45
D
3.5G Module
If you have included an optional 3.5G module in your purchase option follow the instructions
install the USIM card (which will be provided by your service provider), and then install the application.
Before installing the application, make sure that the 3.5G module is on. Use the Fn +
key combination (see
“Function/Hot Key Indicators” on page 1 - 10
) to toggle power to the 3.5G module.
3G Watcher Application Installation
1.
Make sure the module is powered on, and then insert the Device Drivers & Utilities + User’s Manual
CD-ROM (WinXP) into the CD/DVD drive.
2.
Click
Option Drivers
(button).
3. Click 4.3G Driver > Yes.
4. Click Next.
5. Choose your region, and click Next.
6. Click the button to accept the license agreement, and then click Next.
7. Click Next > Next > Install.
8. Click Finish, and the 3G Watcher icon
will appear on the desktop.
9. You can access the 3G Watcher application from the Start menu (Start > Programs/All Programs >
Sierra Wireless > 3G Watcher), or by clicking the desktop icon
.
10. Make sure you enable power to the module by pressing the Fn +
key combination (the icon
will be green).
11. See
“Setting Up a Carrier Profile” on page 7 - 25
“Connecting to the Service Provider” on
for instructions on using the 3G Watcher application.
