Model 702GAS Advanced gas burners — Instruction manual
Carlin part number MN702G Rev. 03/14/11 – 24 –
Where appliance instructions differ from this manual, follow the appliance instructions.
9. Repair parts — Burner housing and components
For parts not shown or listed, contact factory and/or check separate documentation supplied with appliance/burner unit.
Item Description Part No.
1 Blower housing with cover and pressure augmentor NA
7 Airflow switch 98522
8 Honeywell M436 damper motor 35808
9 Gasket 40246
10 14” airtube with pressurized flange; 1” main gas inlet; 1/2” pilot inlet 99541
11 14” combustion head assembly (includes thermal fuse and electrode wire) 57810
12 Blower cover NA
13 Electronic ignitor on baseplate 41000S0LC
14 Motor contactor, Carlin EZ-Contactor 30802
15
Honeywell RM7897C 99766
Subbase for RM7897C 97656
Amplifier for RM7897C 97662
Timing card for RM7897C 97655
16 Motor 27706S
17 Blower wheel 98857KIT
19 Retention ring assembly 56747S
20 Thermal fuse 34215
21 Ignition electrodes Left & Right 98507
22 Ignition wire (One wire in service pack) 55772S
23 14” combustion head support rod 59030S
24 Honeywell C7027A UV scanner 35311
