Quick Start Guide
9
MC22-GB-V1.00
Table showing parameters accessible in OP.b and OP.E and OP.P modes
BASIC
OPR MODE
OP.b
ENHANCED
MODE
OP.E
Program
Editing Mode
OP.P
DESCRIPTION
Home Display
Home
Display
Home Display
OP
SELECTED SETPOINT
CL.ST
CUSTOMER CALIBRATION
OFST
OFFSET FOR 1 POINT CALIBRATION or COEFFICIENT “b”
SLOP
COEFFICIENT “a” (Slope)”
CAL.L
LOW POINT FOR 2 POINT CALIBRATION
OFS.L
OFFSET ON LOW POINT FOR 2 POINT CALIBRATION
CAL.H
HIGH POINT FOR 2 POINT CALIBRATION
OFS.H
OFFSET ON HIGH POINT FOR 2 POINT CALIBRATION
ADr
MODBUS ADDRESS
nPrG
SELECTED PROGRAM
SEG
SEGMENT IN EXECUTION
rT
TIME REMAINING TO THE END OF PROGRAM
r.rPt
REPETITIONS REMAINING TO THE END
rPt
TIME REMAINING UNTIL THE END
PASS
PASWORD TO EDIT PROGRAM 1,2,3
ITSP#
ITSP
INITIAL SET POINT
SP.1#
SP.1
SEGMENT 1 TARGET SET POINT
rr.1#
rr.1
SEGMENT 1 RAMP RATE TO SP 1
TH 1#
TH 1
SEGMENT 1 TIME HELD AT SP 1
SP.2#
SP.2
SEGMENT 2 TARGET SET POINT
rr.2#
rr.2
SEGMENT 2 RAMP RATE TO SP 2
TH 2#
TH 2
SEGMENT 2 TIME HELD AT SP 2
SP.3#
SP.3
SEGMENT 3 TARGET SET POINT
rr.3#
rr.3
SEGMENT 3 RAMP RATE TO SP 3
TH 3#
TH 3
SEGMENT 3 TIME HELD AT SP 3
SP.4#
SP.4
SEGMENT 4 TARGET SET POINT
rr.4#
rr.4
SEGMENT 4 RAMP RATE TO SP 4
TH 4#
TH 4
SEGMENT 4 TIME HELD AT SP 4
Rpt#
rPT
PROGRAM EXECUTION REPETITOINS
CET#
CET
CYCLE END THRESHOLD
# NOTE: In basic mode these parameters are not alterable
