9.0 S PECIFICATIONS
9.1 Models Covered by this Manual
MODEL Max.
Temp. Max.
Power Work
Tube
Bore
Work
Tube
Length Heated
Length Uniform
Zone
Length
1
Net
Weight
2
(°C) (kW) (mm) (mm) (mm) (mm) (kg)
Tube furnaces with a ceramic work tube wound with resistance wire
MTF 10/15/130
1000°C 0.4 15 150 130 30 3
MTF 10/25/130 1000°C 0.4 25 150 130 40 3
MTF 12/25/250 1200°C 0.7 25 300 250 80 10
MTF 12/25/400 1200°C 1.0 25 450 400 130 15
MTF 12/38/250 1200°C 1.0 38 300 250 90 10
MTF 12/38/400 1200°C 1.5 38 450 400 140 15
CTF 12/65/550 1200°C 2.0 65 600 550 260 25
CTF 12/75/700 1200°C 3.0 75 750 700 350 28
CTF 12/100/900 1200°C 4.5 100 950 900 375 35
also models based on the above, but of other diameters or lengths, supplied to special order
note 1: The figures for uniform zone length are for ±5°C and are based on measurements with the
furnace horizontal and fitted with insulating plugs in both tube ends.
note 2: Weights are approximate for horizontal models and do not include fittings or vertical stands.
9.2 Environment
The furnaces contain electrical parts and should be stored and used in indoor conditions as
follows:
temperature: 5°C - 40°C
relative humidity: maximum 80% up to 31°C decreasing linearly to 50% at 40°C
Carbolite reserves the right to change specifications without notice.
