6.0 S PECIFICATIONS
Carbolite reserves the right to change specifications without notice.

Maximum positive pressure – 140mbar (2psi)

Ultimate vacuum – 10
-6
mbar

Operating temperature – safe working limit of the silicone sealing components is 200°C

Nominal work tube outside diameter tolerance range + 1.5mm, -1mm
e.g. size 60mm end seal will work on a tube with outside diameter ranging from 59mmØ to
61.5mmØ
6.1 Environment
End seals should be used within the safe working limits of the furnace to which they are attached.
Materials

304 and 316 stainless steel

Silicone seals
