TLD
MF18 – 3.06
11
8.0 F USES & P OWER S ETTINGS
8.1 Fuses
F1-F2: Refer to the circuit diagrams.
F1
Internal
supply fuses Fitted if supply cable fitted.
Fitted on board to some types of EMC filter. on-board and up to 16 Amps:
32mm x 6mm type F
other: GEC Safeclip
F2
Auxiliary
circuit fuses Fitted on board to some types of EMC filter.
May be omitted up to 25Amp/phase supply
rating. 2 Amps glass type F
On board: 20mm x 5mm
Other: 32mm x 6mm
Customer
fuses Required if no supply cable fitted.
Recommended if cable fitted. See rating label for amperage; see
table below for fuse rating.
F1 - supply
fuses : TLD/3 (220-
240V) 5 Amps TLD/28
(220-240V) 10 Amps
F2 - control
fuses: TLD/3 2 Amps TLD/28 5 Amps
8.2 Power Settings
All models are designed for a power limit ( OP.Hi ) of 100%.
