6
Wide Dual Mini-Vertical Instructions 9-30-13
1.3 Comb Specifications for Hand Cast Gels
1.4 Safety
Power to the Wide Dual Mini-Vertical Electrophoresis System is to be supplied by an
external DC voltage power supply that must be ground isolated so that the DC volt-
age output floats with respect to ground. For any power supply used, the maximum
specified operating parameters for the units are:
Maximum Limits
300 VDC
30 watts power
190mA current
60°C ambient temperature
Current to the unit, provided from the external power supply, must enter the unit
through the lid assembly, providing a safety interlock to the user. Current to the unit
is broken when the lid is removed.
Do not attempt to use the unit without the
safety lid, and always turn the power supply off before removing the lid, or when
working with the unit in any way. Follow safety precautions specified by the
power supply manufacuturer.
COMB OPTIONS
material: PTFE, tooth depth: 9.5mm, overall length: 11.8cm
Cat. # # of
Teeth
Thickness
of Teeth
(mm)
Width of
Teeth (mm)
Recommended Max.
Sample Vol./Well (µl) *
MG15-0712M* 12+2 0.75 7.38 + 3.07 40µl + 16µl (marker)
MG15-0720 20 0.75 4.27 23µl
MG15-0726 26 0.75 2.80 15µl
MG15-1012M* 12+2 1.0 7.38 + 3.07 52µl + 22µl (marker)
MG15-1020 20 1.0 4.27 30µl
MG15-1026 26 1.0 2.80 20µl
MG15-1512M* 12+2 1.5 7.38 + 3.07 78µl + 33µl (marker)
MG15-1520 20 1.5 4.27 45µl
MG15-1526 26 1.5 2.80 30µl
* Maximum loading volume is calculated by taking 75% of the total tooth volume.
*Combs with “M” at end are 12 wells with 2 marker lanes
