21
Diagram #1: LIFT ASSEMBLY
ITEM NO. PART NUMBER DESCRIPTION QTY.
1 42090000 PASSENGER SIDE TOWER ASSEMBLY 1
2 42090001 DRIVER SIDE TOWER ASSEMBLY 1
3 42090003 CROSS BEAM ASSEMBLY 1
4 32100002 POWER UNIT 1
5 42090004 STRAIGHT ARM 2
6 42090005 BEND ARM (DRIVER SIDE) 1
7 42090006 BEND ARM (PASSENGER SIDE) 1
8 22090000 LONG LIFTING ADAPTER 4
9 22090001 SHORT LIFTING ADAPTER 4
10 32090029 M8 NUT 4
11 32090030 8MM LOCK WASHER 4
12 32090031 8MM WASHER 4
13 32090032 M8 BOLT 4
