Baud Rate (0, 1, 2, 3) (40419)
0 = 2400
1 = 9600
2 = 19200
3 = 38400
Parity (0, 1, 2) (40420)
0 = None
1 = Odd
2 = Even
Stop Bit (0 or 1) (40421)
0 = None
1 = 1 stop bit
*Pressure X
x
(40422-40429)
Factory set--do not adjust
•Web Alarming (40430 to 40435)
When the PT-500 is interfaced with an LOE or RST-5002 web-enabled master
device, it can be confi gured to generate website alarms via levelandfl ow.com.
Refer to the LOE or RST-5002 user manual for more informa on about website
alarms and using levelandfl ow.com.
Trip x 1 Level (40430 or 40433)
Sets the level (in mm) to the fi rst actua on point (refer to next page for more
informa on).
Trip x Window (40431 or 40434)
Sets the level (in mm), beginning from the Trip Distance, to the secondary ac-
tua on point (refer to next page for more informa on).
Trip x Type (40432 or 40435)
Determines the opera onal logic performed by the Alarm (refer to next page
for more informa on).
