PT-500 Submersible Pressure Sensor

Rev. A, 5/13

20

Automation Products Group, Inc.

APG...Providing tailored solutions for measurement applications

Tel: 1/888/525-7300 • Fax: 1/435/753-7490 • www.apgsensors.com • [email protected]

Applica on Type 7: Pounds

Allows the user to apply a conversion mul plier to the calculated level reading.

NOTE: the decimal point for the conversion mul plier (40436-40437) is
always assumed to be in the thousands posi on, therefore a se ng of
206250 = 206.250 actual mul plier.

Example: suppose the product in a tank weighs 206.25 pounds for every inch
of level. With the Units set to inches (Units = 2), enter a mul plier of 206250

into Holding registers 40436-40437.

Register Func on

Value Range

40401

Units

1 to 3

40402

Applica on Type

7

40404

Decimal Place

0 to 3

40406

Full Level

0 to Max. Level

40436-40437

Mul plier

0 to 1000000 (1000 = 1.000)
