Applica on Type 2: Volume of cylindrical tank with/without hemispheri-
cal bo om
Register Func on Value Range
40402 Applica on Type 2
40403 Volume Units 1 to 7
40404 Decimal Place 0 to 3
40406 Full Level
40436-40437 Tank Diameter 0 to 100,000 mm
40438-40439 Bo om Radius 0 to 100,000 mm
Diameter
Full
Level
ŽƩŽŵ
Radius
or
