Rev. A, 5/13 PT-500 Submersible Pressure Sensor
13
Automation Products Group, Inc.
APG...Providing tailored solutions for measurement applications
Tel: 1/888/525-7300 • Fax: 1/435/753-7490 • www.apgsensors.com • [email protected]
(con nued)
Register Func on Value Range
40416 Scale *
40417 Off set +/- 2000 mm
40418 Voltage Off set -20 to 20
40419 Baud Rate 0 to 3
40420 Parity 0 to 2
40421 Stop Bit 0 to 1
40422-40423 Pressure X 3 *
40424-40425 Pressure X 2 *
40426-40427 Pressure X 1 *
40428-40429 Pressure X 0 *
40430 Web Alarm 1 Level 0 to 65535
40431 Web Alarm 1 Window 0 to 65535
40432 Web Alarm 1 Type 0 to 29
40433 Web Alarm 2 Level 0 to 65535
40434 Web Alarm 2 Window 0 to 65535
40435 Web Alarm 2 Type 0 to 29
40436-40437 Parameter Data 1 0 to 100,000 mm
40438-40439 Parameter Data 2 0 to 100,000 mm
40440-40441 Parameter Data 3 0 to 100,000 mm
40442-40443 Parameter Data 4 0 to 100,000 mm
40444-40445 Parameter Data 5 0 to 100,000 mm
40446 Temperature Off set -20 to 20
40447-40448 Temperature X 3 *
40449-40450 Temperature X 2 *
40451-40452 Temperature X 1 *
40453-40454 Temperature X 0 *
*factory calibrated--do not adjust
