Rev. A, 5/13

PT-500 Submersible Pressure Sensor

23

Automation Products Group, Inc.

APG...Providing tailored solutions for measurement applications

Tel: 1/888/525-7300 • Fax: 1/435/753-7490 • www.apgsensors.com • [email protected]

Applica on Type 11: Curve Fit

Allows the sensor to mimic a tank strapping chart by using a 3rd degree polyno-
mial equa on to produce a “curve fi t” approxima on.

Register Func on

Value Range

40401

Units

1

to

3

40402

Applica on Type

11

40404

Decimal

Place

0

to

3

40406

Full Level

0 to Max. Level

40436-40437

Parameter 1

0 to 100,000 mm

40438-40439

Parameter 2

0 to 100,000 mm

40440-40441

Parameter 3

0 to 100,000 mm

40442-40443

Parameter 4

0 to 100,000 mm

Open the APG Modbus so ware and select “Strapping Chart” from the “Tools”
menu.

Enter the desired data points
into the table.

Use the “Load” bu on to re-
call a previously saved table.

Import data from an electronic
document by copying the data
and then using the “Paste”
bu on to populate the table.

OR

OR
