ST
AKE-OUT
DIST
ANCE =
UPRIGHT
HEIGHT
WEB GUY - STAKING GUIDELINES
REQUIRED DISTANCE OUT BETWEEN FRAME UPRIGHTS
AND STAKE LINE IS EQUAL TO THE UPRIGHT HEIGHT.
(FOR EXAMPLE, 8’ UPRIGHT = 8’ STAKE-OUT DISTANCE.)
42” Stake driven through stake plate.
Stake must be driven into ground as
far as possible. (1) per upright as
shown for Gabled End Units.
(1) 30” Stake through
base plate. Drive into
ground as far as possible.
1
3
6
5
MCW)
RW ON MID BEAMS, RWE ON END BEAMS
R21-9
U8
BHW
XRB (2) FOR
X-CABLED
BEAMS ONLY
MAKE CONNECTIONS IN NUMBER SEQUENCE
SHOWN. STAKE PLATES BEFORE ERECTING.
* NOTE: B3 AND C50 ABOVE ARE NOT REQUIRED
ON BEAMS THAT HAVE GABLED END FRAMEWORK
ATTACHED.
7
8
9
10
R5-7
B4
B3 *
C50 *
GRW (FOR
END BEAMS
ONLY)
11
12
13
14
15
16
17 18
19 20
ASSEMBLE FIRST BEAM
CAUTION: BRACES
REQUIRED TO AVOID
FRAME DAMAGE!!
9
(1) STAKE PER
BASE PLATE
(1) STAKE PER
BASE PLATE 2
4
