Anchor NAVI-TRAC 50 WIDE GABLE-END - Manual (Page 6)

6
I.D. 50’ GABLED END NAVI-TRAC
LABEL
(LETTER ON
DRAWING)
COMPONENT DESCRIPTION
CODES
(STAMPED OR
TAPED)
GBL
KIT
1
GBL
KIT
2
HIP
KIT
3
20’
MID
STR
20’
MID
EXT
15’
MID
STR
15’
MID
EXT
10’
MID
STR
10’
MID
EXT
CABLES
**OPTIONS OF 10’,15’, OR 20’ BAYS MUST
BE SPECIFIED.
1/2” TENSION LOCK PINS - CROSS CABLE 2 2 2 2 2 2 2 2
X-1
UPRIGHT X-CABLES FOR 10’ MID BAY** GREEN
NAV-BAY10-U8
[4] [4]
INSTALL AS SPECIFIED FOR
UNITS 100’ +
X-2
UPRIGHT X-CABLES FOR 15’ MID BAY** GREEN
NAV-BAY15-U8
[4] [4]
INSTALL AS SPECIFIED FOR
UNITS 100’ +
X-3
UPRIGHT X-CABLES FOR 20’ MID BAY** GREEN
NAV-BAY20-U8
[4] [4]
INSTALL AS SPECIFIED FOR
UNITS 100’ +
X4
LOWER ROOF X-CABLES FOR 10’ MID BAY
A** RED
NAV-BAY10
4 4
INSTALL AS SPECIFIED FOR
UNITS 100’ +
X5
LOWER ROOF X-CABLES FOR 15’ MID BAY
A** RED
NAV-BAY15
4 4
INSTALL AS SPECIFIED FOR
UNITS 100’ +
X6
LOWER ROOF X-CABLES FOR 20’ MID BAY
A** RED
NAV-BAY20
4 4
INSTALL AS SPECIFIED FOR
UNITS 100’ +
X10
UPPER ROOF X-CABLES FOR 10’ MID BAY
C** BLUE
NAV50-BAY10
4 4
INSTALL AS SPECIFIED FOR
UNITS 100’ +
X11
UPPER ROOF X-CABLES FOR 15’ MID BAY
C** BLUE
NAV50-BAY15
4 4
INSTALL AS SPECIFIED FOR
UNITS 100’ +
X12
UPPER ROOF X-CABLES FOR 20’ MID BAY
C** BLUE
NAV50-BAY20
4 4
INSTALL AS SPECIFIED FOR
UNITS 100’ +
BOLTS AND HARDWARE
LANYARD ASS’Y W/HAIRPIN COTTER 8
1/2”-13 x 3” BOLT W/NYLOCK NUT 8 6 18 2 2 2 2 2 2
1/2”-13 x 3 1/2” BOLT W/NYLOCK NUT 7 7
INSTALLATION TOOLS
LOWER SAFETY STRAP W/RATCHET 4
UPPER SAFETY STRAP FOR 10’ BAYS 4
UPPER SAFETY STRAP FOR 15’ BAYS 4
UPPER SAFETY STRAP FOR 20’ BAYS 4
LONG LIFTING CRADLE 1
PUSH POLE EXT. (FOR LONG CRADLE) 1
SHORT LIFTING CRADLE 1
ADJ. BASEPLATE GUIDE BAR 2
FABRIC PULL ROPES 2
WHEELED PANEL GUIDES 2
DROP CLOTH (8’ x 30’) 1
50’ NAVI-TRAC COMPONENT LIST
CONTINUED FROM PREVIOUS PAGE
Other component notes:
1. For X-Cables for units 100’ or longer, see page 13 for quantities and installation.
2. Stakes and Guys are not included in this table. See staking guidelines on Page 9.
