Anchor VENUE SERIES - PROFILE SIZE: 160MM X 100MM - Manual (Page 3)

Introduction
The following instructions describe in a methodical manner the assembly and raising of the Anchor Venue frame tent.
Please read all instructions before the installation or removal of this product.
Work from step to step.
Before erecting any tents or membrane structures, fi rst obtain permits and approvals as required from the local building and
fi re code offi cials on the jurisdiction of your installation.
PLEASE PAY SPECIAL ATTENTION TO SAFETY WARNINGS AND CAUTIONS FOR PREVENTION OF ACCIDENTS.
Regarding the contents of this document:
The illustrations and photos are made to show clearly the construction and dismantling procedures and also for identifi cation
of the components. Not all illustrations/photos correspond to the actual dimensions and size. Explanations and/or notes have
been added to these illustrations/photos.
If you have questions, please call your sales representative at the phone number listed on the front of this manual.
Safety Notes
• Please read through this assembly manual completely before beginning your installation. Be sure the proper equipment
and safety precautions are in place. We hope that you enjoy the design features of the Anchor Venue frame tent each
time the unit is installed.
• Consult your local utility locator service or the National Utility Locating Contractors Association (NULCA) prior to installa-
tion.
• Prior to actual tent assembly, be sure to look up, down, above & below for obstacles, pipes, wires, trouble, etc.Be alert to
avoid contact of frame sections with any overhead power lines near the site.
• Keep site clear of debris to avoid tripping, especially while carrying frame parts or bundle of fabric.
• When moving frame sections by hand, use proper lifting techniques to protect the back, and avoid pinching fi ngers while
making hardware connections.
• The installation method described here requires coordination of tasks between workers. A safe installation is dependent
on that coordination. Work cooperatively as a team.
• Be sure all pins and bolts are installed and secured correctly during assembly.
• Ensure that all purlin hooks are correctly seated in their rafter brackets.
• Replace damaged or worn components with Anchor OEM components.
• To prevent injuries, wear suitable protective clothing such as hard hats, steel toed shoes, etc.
• Do not drag bundle of fabric on concrete, asphalt, or ground as this can cause damage to the fabric from abrasion through
the bag.
• This tent is manufactured for use as a temporary structure. Evacuation is recommended if threatening or windy weather
occurs. See caution on back page of this manual.
