AP3876 – Addendum to User Guide – Software Update V2.01
5
E
XTENDED
MIDI C
ONTROL
PARAMETER CONTROL Every console parameter is now mapped for independent MIDI
control. This is based on the NRPN system with the MSB selecting the channel number, and
the LSB selecting the parameter number in that channel (channel type specific).
Channel selection message:
0xBm, 0x63,
Where
0x00 =
CH1 to 0x07 = CH8, 0x08 = FX1, 0x09 = FX2, and
0x40 =
GEQA, 0x41 = GEQB.
Parameter selection message:
0xBm, 0x62,
(Controller 98)
Where is shown below:
Parameter values are set using Data Entry MSB:
0xBm, 0x06,
All parameter values are ‘normalised’ from 0x00-0x7F
Device Parameter
Parameter ID
LF Gain
0x01
LF Frequency
0x02
LMF Gain
0x03
LMF Frequency
0x04
LMF Q
0x05
HMF Gain
0x06
HMF Frequency
0x07
HMF Q
0x08
HF Gain
0x09
HF Frequency
0x0A
PEQ
In/Out
0x0B
Drive
0x0C
Attack
0x0D
Release
0x0E
Knee
0x0F
Compressor
In/Out
0x10
Level
0x11
Attack
0x12
Decay
0x13
Gate
In/Out
0x14
Aux
Send Level
0x15
Foldback
Send Level
0x16
Trim
Level
0x17
Pan/Balance
Pan/Balance
0x18
FX1
Send Level
0x19
FX2
Send Level
0x1A
Fader Level
Level (transmit only, no recieve)
0x1B
Band Gain
0x00 Lowest Band 31Hz
0x09 Highest Band 16kHz
In/Out
0x20
GEQ
Linking
0x21
When linked, both GEQA&B messages (for
band gain & in/out) are generated by the I-CON
