25
device you wish to connect. When you’re adding a profile from an
existing access point or wireless device, the encryption type will
be selected automatically, and please do not modify it.
WPA
Preshared Key Input WPA preshared key here. If encryption is not enabled, or
you select ‘WEP’ as encryption type, this field will be disabled and
grayed out.
WEP Key You can select key type (Hexadecimal or ASCII) and input WEP
key here. If encryption is not enabled, or you select ‘WPA’ as
encryption type, this field will be disabled and grayed out. You can
set up to 4 WEP keys here.
There are two types of WEP key: Hexadecimal and ASCII. For
Hexadecimal key, you can input number 0-9 and alphabet a-f; for
example, ‘001122aabbcc’; For ASCII key, you can input number
0-9 and alphabet a-z; for example, mywepkey12345.
The length of WEP key depends on the type of WEP key you
selected. You can input 10 or 26 hexadecimal characters and 5 or
13 ASCII characters as WEP key.
Show
Password Check this box and all passphrases or security keys you inputted
will be displayed as you type, but not replace your input with
asterisk.
Use 802.1x If the access point you wish to connect requires 802.1x
authentication, please click on ‘Use 802.1x’ box, then click
‘802.1X’ tab to set 802.1x parameters.
To set 802.1x authentication for the access point. Please click ‘802.1X’ tab:
Here are descriptions of every setup item:
