AirLive WN-151ARM User’s Manual

Routing Screen

RIP

RIP Direction

Select the desired RIP Direction.

RIP Version

Choose the RIP Version for the Server.

Static Routing

Table Entries

This list shows all entries in the Routing Table.

• This area shows details of the selected item in the list.

• Change any the properties as required, then click the "Edit" button

to save the changes to the selected entry.

Buttons

Add

Add a new entry to the Static Routing table, using the data shown in the

"Properties" area on screen. The entry selected in the list is ignored,

and has no effect.

Edit

Update the current Static Routing Table entry, using the data shown in

the table area on screen.

Delete

Delete the current Static Routing Table entry.

Save

Save the RIP setting. This has no effect on the Static Routing Table.

Configuring Other Routers on your LAN

It is essential that all IP packets for devices are not on the local LAN be passed to the WN-151ARM, so that

they can be forwarded to the external LAN, WAN, or Internet. To achieve this, the local LAN must be

configured to use the WN-151ARM as the Default Route or Default Gateway.

Local Router

The local router is the Router installed on the same LAN segment as the WN-151ARM. This router requires

that the Default Route is the WN-151ARM itself. Typically, routers have a special entry for the Default Route.

It should be configured as follows.

Destination IP

Address

Normally 0.0.0.0, but check your router

documentation.

Network Mask

Normally 0.0.0.0, but check your router

documentation.

Gateway IP Address

The IP Address of the WN-151ARM.

Metric
