AirLive WN-151ARM User’s Manual 50
Connection Details - Fixed IP Address
If your access method is "Direct" (no login), with a fixed IP address, a screen like the following example will be
displayed when the "Connection Details" button is clicked.
Figure: Connection Details - Fixed/Dynamic IP Address
Fixed IP address Screen
Internet
IP Address The IP Address of this device, as seen by Internet users. This address is
allocated by your ISP (Internet Service Provider).
Subnet Mask The Subnet Mask associated with the IP Address above.
Default
Gateway
The IP Address of the remote Gateway or Router associated with the IP
Address above.
DNS Server The IP Address of the Domain Name Server which is currently used.
