AirLive WN-151ARM - Manual (Page 46)

AirLive WN-151ARM User’s Manual 46
Wireless
SSID 1 It displays the name of the SSID 1.
SSID 2 It displays the name of the SSID 2.
Region The current region, as set on the Wireless screen.
Channel This shows the Channel currently used, as set on the Wireless screen.
Wireless AP This indicates whether or not the Wireless Access Point feature is
enabled.
Broadcast Name This indicates whether or not the SSID is Broadcast. This setting is on the
Wireless screen.
System
Device Name The current name of the device. This name is also the "hostname" for
users with "@Home" type connection.
Firmware Version The version of the current firmware installed.
Buttons
Connection
Details
Click this button to open a sub-window and view a detailed description of
the current connection.
Attached Devices This will open a sub-window, showing all LAN and Wireless devices
currently on the network.
Refresh Screen Update the data displayed on screen.
Help The description of Status item.
