AirLive WN-151ARM User’s Manual 32
Options
802.11 Mode Select the desired mode:
• Off - Wireless function is off.
• 11b only – this device will only allow 802.11b wireless network clients
to connect to it. (Maximum transfer rate is 11Mbps)
• 11g only –this device will only allow 802.11g wireless network clients
to connect to it. (Maximum transfer rate is 54Mbps)
• 11b + 11g – this device will only allow 802.11b and 802.11g wireless
network clients to connect to it.
• 11b/g/n – this device will allow 802.11b, 802.11g or 802.11n wireless
network clients to connect to it.
Channel No. Select the Channel you wish to use for your wireless LAN.
• If you experience interference (shown by lost connections and/or slow
data transfers) please try to assign a different channel to avoid signal
collision.
• If using multiple Access Points, adjacent Access Points should use
different Channels to reduce interference.
Extension
Channel
This option will be selectable under the following conditions:
802.11 Mode: 11b+g+n
Bandwidth: 20MHz + 40MHz auto
Channel No.: Channel 5 ~ 9
40MHz spectrum transmission will use up to 5 wireless channels, therefore,
between channel 5 ~ 9, you can choose “Up channel” or “Down channel”.
For example, channel 5 and up channel is selected, which means the
wireless spectrum transmission will use channel 1 ~ 5.
Isolation
between SSID
If Enabled, SSID1 and SSID2 will be isolated and operating independently.
SSID1 users and SSID2 users will not be able to see each other.
WMM Support Wi-Fi Multi Media (WMM) enhances the data transfer performance of
multimedia contents when they’re being transferred over a wireless
network.
Note: This function can only be available when client’s wireless card also
supports WMM feature.
Bandwidth Select the desired bandwidth from the list.
Note: Do not modify the default value if you aren’t familiar with this function.
