AirLive WMU-6500FS User’s Manual 8
Backup Press the button for 4 seconds to copy data from
attached USB device to HDD.
Reset Press the buttons of “Shutdown” and “Backup”
simultaneously for 6 seconds to reset the system
setting to factory default.
Rear Ports:
Ports Description
Antenna Connect 2.4GHz dipole antenna.
LAN Automatically MDI / MDIX LAN port can sense the
cable type when connecting to Ethernet-enabled
computer, network of hub, switch, or router.
USB1 / USB2 The ports where you can connect to USB disk, digital
camera, or card reader.
Power Switch Switch on/off the device.
Power Jack 12V / 4A power inlet.
1.6 LED Indicators
LED Light Off Solid Light Blinking
Power Power off Power on
W.LAN No packet On transmitting
LAN No device Linked On transmitting.
HDD R/W Not in use HDD read/write
HDD Status No HDD HDD full or error More blinking
quickly, fewer
available HDD
capacity.
USB 1 No device USB drive ready
USB 2 No device USB drive ready
