10
NOTE: Only full duplex mode is supported in 1Gbps link speed. For copper medium, this
system doesn’t support 1Gbps link speed in force mode; for fiber medium, only the 1Gbps
link speed is supported, but either auto or force mode can be set to build up the link.
„ Flow Control – to enable/disable flow control function
¾ Disable -- to disable for the port
¾ Enable – to enable for the port
„ Default Priority – to setup the priority of frames which will referenced in QOS function
¾ 0 – 7 – to set the priority level (range = 0 ~ 7)
„ Security – to enable/disable port security function
If the per-port security is enabled and if a received frame contains a source MAC address that
has already been learned in another port’s address table but not aged out, then the frame is
dropped. Otherwise, the address table entry is updated with the new port’s information and the
entry is updated.
¾
Disable -- to disable port security
¾ Enable – to enable port security
„ Jumbo Frame – to enable/disable jumbo frame function
If the per-port jumbo frame feature is enabled, the maximum frame size is 9216 bytes. In 100
Mbps mode, the maximum jumbo frame size supported is 9000 bytes
¾
Disable -- to disable jumbo frame support
¾ Enable – to enable jumbo frame support
After the desired options are selected for the above functions, click the Apply button to save the
current settings to the switch and back to the Port Status Page. Click the Cancel button to back to
Port Status page.
