2. Package Contents and Installation
AirLive BC-5010 User’s Manual 10
„ MIC in (audio in): Connect a microphone to the network camera.
„ Audio out: Connect a loud speaker to the network camera. This function is for
voice alerting and two-way audio.
5. Iris Level: It is used only when the DC-Iris lens is connected to the camera. This
screw-knob allows you to adjust the brightness of the video images from the DC-Iris lens.
6. SD Card Slot: SD Card Slot allows you to insert a memory card for expansion of
storage.
7. USB Port: USB Port connects external USB device, such as flash drive or USB wireless
adapter.
8. BNC connector: BNC connector can connect monitor to check camera focus and video
quality.
9. Reset Button: This button is used to restore all the factory default settings. Sometimes
restarting the device will make the system back to a normal state. However, if the system
still has problems after restart, user can restore the factory default settings and install it
again.
Restore the device:
1.) Press the button down continuously.
2.) Hold the button at least 5 seconds and release it. Then the device has been
restored to default settings and reboot again.
Note: Restoring to the factory default settings will lose all the previous settings
included IP address forever. User needs to run the IPWizard II program to search the
device and configure it to let the device work properly again.
2.3 Connections Mounting the Camera
1. Attaching the Wall Mount Kit
The Wall Mount Kit that is provided in the package has a swivel ball screw head, so that
you can attach it to the screw hole on the camera’s top (or bottom) panel.
After attaching the camera to the Wall Mount Kit, the camera can be mounted on the wall
or ceiling securely through the three screw holes on the base of the Wall Mount Kit.
