26
5.2
Channels sampled by MXL with 2008-2011 protocol
ID CHANNEL NAME FUNCTION
ECU_1 SSM_RPM RPM
ECU_2 SSM_SPEED Vehicle Speed
ECU_3 SSM_TPS Throttle Position sensor
ECU_4 SSM_ECT Engine cooling temperature
ECU_5 SSM_TURBO_PRES Turbo pressure
ECU_6 SSM_IN_VVT_R Right bank inlet timing
ECU_7 SSM_IN_VVT_L Left bank inlet timing
ECU_8 SSM_IGN_ADV Ignition advance
ECU_9 SSM_KNOCK_CORR Advances correction depending on detonation sensor
ECU_10 SSM_FUEL_LEV Fuel level
ECU_11 SSM_NEUTRAL Neutral sensor
ECU_12 SSM_CLUTCH Clutch disengaged signal
ECU_13 SSM_BRAKE Brake switch
ECU_14 SSM_ENG_LOAD Instant engine load
ECU_15 SSM_AIR_FLOW Air flow in the air pipes
ECU_16 SSM_EX_VVT_R Right bank exhaust timing
ECU_17 SSM_EX_VVT_L Left bank exhaust timing
ECU_18 SSM_SEL_MAP Selected Map
ECU_19 SSM_GEAR Engaged gear
