Gear calibration
Gear calibration is the last step of MXL configuration. The procedure is as follows:
•
press “MENU” on MXL keyboard until it shows “START GEAR CALIB”;
•
press “OK”;
•
it shows “PRESS OK TO CLEAR”;
•
press again “OK”: the logger is ready to start calibration;
•
leave, avoiding disengaging the clutch; you have to run an “apprentice lap”: engage all gears and
keep each gear engaged for some seconds;
•
stop the car and switch it off but do not disengage the clutch or pull it;
•
switch MXL on again: the display shows “CALIBRATION OK”; in case the procedure has been
unsuccessful the display shows “ERROR GEAR CALC” and the device automatically re-starts the
procedure: repeat the apprentice lap. It may occur that MXL shows “CALIBRATION OK” but stored
values are incorrect. In this case repeat the calibration.
