Data sheet, Ace backstage co., inc, Stage pocket systems – ACE BACKSTAGE Super Double Wide Stage Pocket User Manual

Page 5

SUPER DOUBLE WIDE STAGE POCKET SPECIFICATIONS

ACE BACK

STAGE CO., IN

CLEAR C

DMX12

PUSH

"CONNECTRIX" PANEL

SYSTEM

COMBINATION OF "#PNL-100",

"#PNL-120", OR "#PNL-140"

STAGE POCKET

PANELS

8.000"

TRIM BEZEL

MOUNTING

FLANGE AND

LID ASSEMBL Y

LID STOP WITH RUBBER PAD, 2 P

LACES

(2) HINGED CABLE WA

Y S LOT CLOSURES

NOMINAL

OPENING

REMOVABLE SPRING LOADED

HINGE PINS PERMIT EASY LID

EXCHANGE FOR CARPET, LOCKING,

AND STANDARD LID CONFIGURA

TIONS

LID (BLIND HINGE),

SPRING LOADED PINS,

AVA ILABLE IN STANDARD

FLUSH , STANDARD FLUSH

LOCKING, OR RECESSED

CARPET

6.000"

1.000"

10.000"

5.000"

RIGHT SIDE SECTION

FRONT SECTION

3.281"

2.375"

18.000"

16.250"

COMBINATION KNOCK-OUTS

1/2", 3/4", AND 1-1/4", 2 PLACES

TYPICAL ON OPPOSING SIDES

COMBINATION KNOCK-OUTS

1/2" AND 3/4", 1 PLACE

TYPICAL ON OPPOSING SIDES

SUPER DOUBLE WIDE

STAGE POCKET

BACK BOX #BRK104BBX

14 GAUGE SHEET STEEL

CRS (.071" THICK) WITH

A C LEAR ZINC FINISH

SUPER DOUBLE WIDE

STAGE POCKET

BACK BOX #BRK104BBX

14 GAUGE SHEET STEEL

CRS (.071" THICK) WITH

A C LEAR ZINC FINISH

"CONNECTRIX" PANEL

SYSTEM

COMBINATION OF "#PNL-100",

"#PNL-120", OR "#PNL-140"

STAGE POCKET

PANELS

1.312"

.937"

1.312"

.375" CABLE WA

Y S LOT

18.500"

16.000"

1.250" TYPICAL TRIM BEZEL

10.500"

TOP VIEW

15.376"

11 GAUGE (.120" THICK) STEEL TRIM BEZEL

MOUNTING FLANGE AND LID ASSEMBL

WITH POWDER COAT FINISH INSIDE A

ND OUTSIDE

• ANTIQUE COPPER VEIN

• ANTIQUE SILVER VEIN

• TEXTURED BLACK

• BRUSHED BRASS*

• STAINLESS ST

EEL*

*Solid Brass or Stainless Steel Metal

Finish Available as Special Order

TOP VIEW

.500"

SET THE SUPER ST

AGE POCKET

BACK BOX #BRK104BBX SECURELY

BRACED INTO T

HE FLOOR TO PROVIDE

SUPPORT EQUAL T

O THE FLOOR

LOADING REQUIREMENTS, ACCOUNTING

FOR ANY HEIGHT OFFSET REQUIRED

FOR THE FINISHED FLOOR

5 of 6

ACE BACKSTAGE CO., INC.

STAGE POCKET SYSTEMS

24846 Avenue Rockefeller | Suite 200 | Valencia, CA 91355

Tel: 661-295-5760 | Fax: 661-295-1122

Email: [email protected] | Web: www.acebackstage.com

DATA SHEET

Stage Pocket

Data Spec Sheet

Revision: 1A.134-234

Model Numbers:

#134-xxyy, #234-xxyy (xx= Lid Type and yy= Finish Type)

Model Name:

Super Double Wide Stage Pocket - Super Double Capacity Horizontal Panel Pocket

Model Description: Pocket with brushed metal or powder coat finish, choice of lid, with optional panel(s) and connectors
