oven cured powder coat electro-static applied inside and

outside entire Trim Bezel Lid and Mounting Flange assem-

bly. Decorator neutral Antique Copper Vein and Textured

Black finishes are standard. A Solid Brass Trim Bezel Lid

and Mounting Flange with a brushed finish is also available

by special order. Super Double Wide Stage Pocket Body

Back Box is finished with a clear Zinc, Mil Spec QQ-Z-325E

Type I, Class II.

• RUBBER LID STOPS: Rubber lid stops set into recessed

mount cradle the lid to prevent lid rattle.

• UL LISTED: Super Double Wide Stage Pockets compli-

ance Standard 514A in combination with inner floor pocket

file FLOOR BOX 44LK.

MATERIALS

ACE Super Double Wide Stage Pocket Trim Bezel Mounting

Flanges are made of 1/8” (nominally 11 ga. (.120”)) thick

CRS steel, the Lid is made from 10 ga. (nominally .135”)

thick CRS steel, and the Super Double Wide Stage Pocket

Body Back Box is made from 14 ga. (.071”) thick CRS

steel. The exception to this is the Brass Super Double Wide

Stage Pocket Trim Bezel Lid and Mounting Flange which is

made of 1/8” (nominally 11 ga. (.120”)) thick Half Hard

Solid Brass.

FINISHES

ACE Super Double Wide Stage Pockets come with a scratch/

wear resistant finish, oven cured powder coat electro-static

applied inside and outside the entire Trim Bezel Lid and

Mounting Flange assembly. Decorator neutral Antique

Copper Vein and Textured Black finishes are standard.

A Solid Brass Trim Bezel Lid and Mounting Flange with a

brushed finish is also available by special order*.

INCLUDES

ACE Super Double Wide Stage Pockets Include:

• (1) Super Double Wide Pocket Body Back Box w/Brackets

• (1) Trim Bezel Lid and Mounting Flange Assembly

• (1) Lid (Standard w/ option for Carpet, Locking etc.)

• (2) Hinged Slot Closures

• (2) Hinge Pins

• (2) Springs

• (12) #8 Self Tapping Sheet Metal/Wood Screws

SPECIFICATIONS

ACE Super Double Wide Stage Pocket Size:

• Super Double Wide Stage Pocket Body Back Box Size:

10.000” W x 6.000” H x 18.000” D

• Super Double Wide Pocket Trim Bezel Lid & Mounting

Flange Size:

10.500” W x 0.937” H x 18.500” D

ACE Super Double Wide Stage Pocket Connector

Capacity:

• 48 “Connectrix”, Neutrik®, or Switchcraft® Connectors

ACE Super Double Wide Stage Pocket Install Cutout

Dimensions:

• 10.000” W x 18.000” L

ACE Super Double Wide Stage Pocket Material:

• CRS Steel and/or Solid Half Hard Brass

ACE Super Double Wide Stage Pocket Panel

Capacity:

• (8) #PNL-100 Series “Connectrix” Panels OR

• (8) #PSW-100 Series Switchcraft® Panels OR

• (4) #PNL-120 Series “Connectrix” Panels OR

• (2) #PNL-140 Series “Connectrix” Panels OR

• Various multi panel combinations from panels listed above

CONNECTOR CAPACITY

ACE Super Double Wide Stage Pockets Connector

Capacity:

• 48 “Connectrix”, Neutrik®, or Switchcraft® Connectors

“CONNECTRIX” Connectors combine Neutrik® “D”

and Switchcraft® “E” Mounting Hole Patterns for

Greater Flexibility

The “CONNECTRIX” system connectors may be used in

any of the “CONNECTRIX” system panels utilizing our

“CONNECTRIX” cutout which incorporates the popular

mounting pattern of the Neutrik “D” and Switchcraft “E”

series mounting patterns. Connectors using the generous

rectangular “CONNECTRIX” cutout will add to a growing ar-

ray of adapter-mounted standard connectors. The adapter

mount is plastic and provides ground isolation between the

panel and connector.

When ordering, please specify connector model number,

model name, and type of connector as well as panel model

number (#PNL-100 Series, #PNL-120 Series, or #PNL-140

Series) the connectors will be loaded into. NOTE: Specific

High Density (HD) and Sub-D pattern connectors will re-

quire either 2 or 3 “CONNECTRIX” Horizontal Spaces or 2

or 3 “CONNECTRIX” Vertical Spaces, depending on connec-

tors selected. Connectors may be loaded into panels with

nutcerts and nut/bolts or black aluminum pop rivets.

ACE Super Double Wide Stage Pockets Connector

Types:

• “Connectrix” Connectors (fits Neutrik®/Switchcraft®)

• Switchcraft® Connectors

• Custom Panel Connectors (custom panel cutout required)

CONTINUED...

ACE BACKSTAGE CO., INC.

STAGE POCKET SYSTEMS

24846 Avenue Rockefeller | Suite 200 | Valencia, CA 91355

Tel: 661-295-5760 | Fax: 661-295-1122

Email: [email protected] | Web: www.acebackstage.com

DATA SHEET

Stage Pocket

Data Spec Sheet

Revision: 1A.134-234

Model Numbers:

#134-xxyy, #234-xxyy (xx= Lid Type and yy= Finish Type)

Model Name:

Super Double Wide Stage Pocket - Super Double Capacity Horizontal Panel Pocket

Model Description: Pocket with brushed metal or powder coat finish, choice of lid, with optional panel(s) and connectors

*NOTE: Connector capacity limitations apply depending on connectors and panels used.
