Connection:

Security Relay

The

(Part No. 9159010) is used for enhancing security between the

Security Relay

intercom and the connected electric lock. The

2N Helios IP Security Relay

designed for any

intercom model with firmware versions 1.15 and

2N Helios IP

higher. It significantly enhances security of the connected electric lock as it prevents
lock opening by forced intercom tampering.

Function:

The

is a device installed between an intercom (outside

2N Helios IP Security Relay

the secured area) and the electric lock (inside the secured area). The 2N Helios IP

includes a relay that can only be activated if the valid opening code is

Security Relay
r e c e i v e d

f r o m

t h e

i n t e r c o m . . R e f e r

t o

t h e

for details.

Specifications:

Passive switch: NO and NC contacts, up to 30 V / 1 A AC/DC
Active switch output: 12 V / 700 mA DC
Dimensions: 56 x 31 x 24 mm
Weight: 20 g
