Page 14
12
feaTureS & conTrolS
understanding how your machine works will help you achieve the best results when using your chipper. the following
descriptions define the features and controls of your machine.
ReFeR to eNgINe oWNeRS MaNual FoR FuRtHeR eNgINe oPeRatINg INStRuCtIoNS.
9. Chipper
Chute
8. Extension
Tray
10. Reset Button
15. Rear
Stabilizer
14. Bottle Jack
12. Fuel
Gauge
11. Fuel Tank
13. Discharge
Chute Rotor
6. Feed Roller
Engagement
7. Safety Bar
1. Chipper
Engagement
4. Tongue Jack
5. Discharge Cap Crank
3. Control
Panel
2. Control
Switch
Section
3
