31
Video
A. Connecting to a video source
The Projector can receive composite Video/stereo-audio, S-Video or Component video
(YCbCr) signals.
1.
Th
e composite video an
d ster
eo-audio
inputs, are the yellow, white and red RCA
connections on the projector. Con
nect the yellow RCA plug at
one end of the
video/ster
eo-audio cable to th
e
yellow video jack. Con
n
ect th
e oth
er
yellow RCA plug to the video-out Jack on the video source.
2.
The red and white connections are audio connections. To use the projector speakers
connect the audio cable between the projector and the audio source as shown below.
2.1.
Insert the white plug into the L-Jack and red plug into the R-Jack.
2.2. Con
n
ect th
e
other end of the cable to the output jacks of th
e
audio sour
ce.
3. For S-Video, in
sert one en
d of th
e S-Video cable in
to th
e pr
ojector’s S-Video jack.
In
ser
t th
e oth
er en
d in
to th
e S-Video out jack on your S-Video sour
ce.
3.
1.
& 2.
Video
