Names and Function of Each part
Main Unit
3.Lamp Cover
Outlet Ventilation
Speaker
10.Con tr ol pan el
(Keyp ad)
5.Rear adjustable foot
8.Handle
4.Filter cover
5.Front adjustable foot
2.Focus Ring
1.Zoom Ring
6.Foot adjuster button
9.Lens cover
7.IR receiver
1.Zoom Ring
Use the Zoom Ring to adjust the size of the projected image.
Rotate the Zoom Ring until the image is the desired size.
2.Focus Ring
Use the Focus Ring to focus the projected image.
Rotate the Focus Ring until the image is clear.
