3.Lamp cover
Remove the Lamp cover to replace the old lamp.
CAUTION
Allow the lamp to cool for 1 hour prior to replacing the lamp.
Turn off power before opening this lamp cover. Replace with same type lamp rated.
4.Filter cover
Prevents dust and other foreign particles from being drawn into projector.
Remove the Filter cover to clean the air filter.
5.Front / Rear adjustable foot
Extend and retract to adjust the projection angle
6.Foot adjuster button
Lock/unlock the adjustable foot.
7.IR receiver
When using the remote control, point the remote control at this sensor
8.Projector handle
Holding the projector when lifting and transporting.
9.Lens cover
Attach when not using to protect the lens from becoming dirty or
damaged
10.Control panel ( key pads )
Operating system.
