708E 4460761 Connector, Female - 4 Position 1
4460227 Pin, Male 4
708F 4460909 Connector - 12 Position (Black) 1
4460915 Wedge Lock - 12 Position 1
4460928 Socket, Female 6
708G 4460908 Connector - 12 Position (Gray) 1
4460915 Wedge Lock - 12 Position 1
4460928 Socket, Female 5
708H 4460965 Connector, Male - 3 Position 1
4460944 Socket, Female (Gold) 3
708J 4922099 Cable, Can-Buss (Machines with Can Buss Engine
Controllers & Caterpillar Engine without Can Buss
Engine Controllers) AR
4460965 Connector, Male - 3 Position 1
4460944 Socket, Female (Gold) 6
4460539 Terminal, Plug - 3 Position 1
708K 4922099 Cable, Can-Buss (Machines without Can Buss
Engine Controllers) AR
4460965 Connector, Male - 3 Position 1
4460944 Socket, Female (Gold) 6
4460464 Pin, Male Deutsch (16 Gauge) 3
708L 4922099 Cable, Can-Buss (Machines without Can Buss
Engine Controllers) AR
4460539 Terminal, Plug - 3 Position 2
4460944 Socket, Female (Gold) 6
708M 4460536 Terminal, Receptacle - 3 Position (Machines with-
out Can Buss Engine Controllers) 1
709 1001093187 Tilt Sensor Installation Ref C
4460945 Receptacle - 3 Position (3 way Tee) 1
OPTIONAL HARNESS COMPONENTS Ref
801 4921928 4WS Valve Harness 1
801A 4460268 Socket, Female 3
801B 4460445 Connector, Female - 3 Position 1
801C 4460499 Connector, DIN with Diode 2
802 4921927 Jib Valve Harness (800AJ Only) 1
802A 4460326 Plug, Male - 3 Position 1
802B 4460267 Pin, Male 3
802C 4460499 Connector, DIN with Diode 2
803 0257887 Alarm Harness (Includes Alarm) 1
803A 4460424 Plug, Male - 2 Position 1
803B 4460268 Socket, Female 2
804 0255917 Strobe Light Harness (Includes Strobe Light) 1
804A 4460320 Connector, Female - 2 Position 1
804B 4460267 Pin, Male 2
FIGURE 7-3. HARNESS COMPONENTS INSTALLATION (WITH ADE SYSTEM) (SN 0300064432 TO
SN 0300069000)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
