3120859 5-7
SECTION 5 CYLINDER
S
E
C
T
I
O
N
5
C
Y
L
I
N
D
E
R
FIGURE 5-3. LIFT CYLINDER ASSEMBLY - JIB (800AJ ONLY)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
1683609 JIB LIFT CYLINDER ASSEMBLY Ref D
1 Barrel Weldment Options: (Note: Includes Item 1A) 1
1683687 Prior to SN 0300062045
1684089 SN 0300062045 to SN 0300069000
1A Bushing Options: 2
0961947 Prior to SN 0300054012
0962336 SN 0300054012 to SN 0300069000
2 1683053 Head 1
3 3760368 Washer, Ring 1
4 3931516 Bolt, Socket Head 5/1in-18NC x 2in 8
5 Rod Weldment Options: (Note: Includes Item 5A) 1
1683261 Prior to SN 0300062045
1684090 SN 0300062045 to SN 0300069000
5A Bushing Options: 2
0961947 Prior to SN 0300054012
0962336 SN 0300054012 to SN 0300069000
6 4640509 Cartridge, Valve (Counterbalance Non-Vented) 2
2900792 Seal Kit - 4640509 Valve 2
7 4641062 Plug, P.O. Check 1
8 2220883 Plug, O-Ring 4
9 2220885 Plug, O-Ring 1
10 3480210 Piston 1
11 0961893 Bushing, Tapered 1
12 4566471 Spacer, Tube 1
13 3900141 Setscrew 1/4in-20NC x 1/4in 1
14 Use 2901303 Ring, Lock 2
15 Use 2901303 Seal, Piston 2
16 Use 2901303 O-Ring 1
17 Use 2901303 Ring, Back-up 2
18 Use 2901303 O-Ring 1
19 Use 2901303 Ring, Back-up 1
20 Use 2901303 Seal 1
21 Use 2901303 Wiper 1
22 Use 2901303 Ring, Wear 1
23 0100011 Compound, Locking AR
24 0100038 Primer, Locking AR
25 0100063 Loctite #RC609 AR
26 0630534 Capscrew, Socket Head #10-24NC x 1in 3
27 to 29 Not Used
30 2901303 Seal Kit (Includes Items 14-22) 1
