3120859 3-11
SECTION 3 BOOM
S
E
C
T
I
O
N
3
B
O
O
M
.
FIGURE 3-3. TOWER BOOM ASSEMBLY
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
0801132 TOWER BOOM ASSEMBLY Ref C
1 0801133 Base Weldment 1
2 0801134 Fly Weldment 1
3 1683606 Cylinder Assembly - Tower Telescope (See CYLINDER
SECTION for Breakdown) 1
4 4340706 Support 1
5 0561185 Block, Attach 4
6 4070929 Shim 1/16in 8
7 0962102 Bushing, Garmax 2
8 0962122 Bushing, Garmax 2
9 Pad, Wear Options: 12
3340756 Prior to SN 0300064695
3340881 SN 0300064695 to SN 0300069000
10 4070897 Shim .05 8
11 4070898 Shim .12 8
12 3340828 Pad, Wear 2
13 4070967 Shim .05 2
14 4070968 Shim .12 2
15 0641607 Bolt 3/8in-16NC x 7/8in 10
16 0641608 Bolt 3/8in-16NC x 1in 4
17 0641609 Bolt 3/8in-16NC x 1-1/8in 4
18 0641610 Bolt 3/8in-16NC x 1-1/4in 12
19 0641615 Bolt 3/8in-16NC x 1-7/8in 8
20 0641616 Bolt 3/8in-16NC x 2in 8
21 4711600 Flatwasher 3/8in Narrow 6
22 0100011 Compound, Locking AR
23 0100038 Primer, Locking AR
24 3340835 Pad, Boom Rest 1
25 0641806 Bolt 1/2in-13NC x 3/4in 3
0257764 POWER TRACK INSTALLATION Ref F
101 1180346 Carrier 1
7020064 Bracket, End (Moving) 1
7020065 Bracket, End (Fixed) 1
7020066 Section, Repair 1Foot 1
7020067 Link, Repair 1
102 4845680 Hose Tube Weldment 1
103 1320251 Clamp, Block 2
104 1320250 Bar, Clamp 2
105 0100011 Compound, Locking AR
106 0100038 Primer, Locking AR
107 0641605 Bolt 3/8in-16NC x 5/8in 4
108 0641606 Bolt 3/8in-16NC x 3/4in 2
109 0641622 Bolt 3/8in-16NC x 2-3/4in 2
110 3311601 Nut 3/8in-16NC 4
111 3311602 Nut, Jam 3/8in-16NC 2
