JLG 800A_AJ Parts Manual - Manual (Page 235)

3120859 7-21
SECTION 7 ELECTRICAL
S
E
C
T
I
O
N
7
E
L
E
C
T
R
I
C
A
L
GROUND CONTROL BOX COMPONENTS Ref
401 to 416 Not Used
417 3740049 Relay 1
418 to 425 Not Used
426 4460426 Connector, Strain Relief 2
427 4460470 Nut, Terminal 1
428 4460471 Lockwasher, Terminal 1
429 Not Used
430 4460526 Connector, Strain Relief 1
431 4460874 Connector (Natural) 1
432 4460875 Connector (Gray) 1
433 4460905 Connector, Amp Seal Plug 4
434 to 436 Not Used
437 4922549 Deutz Engine Harness Assembly (Not Shown - See
501 to 700 for Breakdown) 1
438 4922557 Valve Harness Assembly 1 1/A
438A 4460880 Connector, DIN 19
438B 4460320 Connector, Female- 2 Position 2
4460267 Pin, Male 7
438C 4460424 Connector, Male- 2 Position 1
4460268 Pin, Female 5
438D 4460871 Socket, Female AR
438E 4460326 Connector, Male - 3 Position 1
4460267 Pin, Male 7
438F 4460445 Connector, Female - 3 Position 1
4460268 Pin, Female 5
439 Ground Control Box Harness Assemblies 1
4922638 Prior to SN 0300064493 1 4/E
4922675 SN 0300064493 to SN 0300069000 1 3/C
439A 4460418 Connector, Female- 6 Position 9
4460419 Socket, Female 27
439B 4460876 Connector, 35- Position 1
4460871 Socket, Female AR
4460905 Seal, Plug 28
439C 4460866 Connector - 19 Position 1
4460464 Pin, Male Deutsch (16 Gauge) 10
439D 4460878 Housing, Terminal- 4 Position 1
4460887 Terminal (12 Gauge) 3
439E 4120035 Base, Light AR
4460634 Terminal (16 Gauge) AR
439F 4460873 Connector - 35 Position (Black) 1
4460871 Socket, Female AR
4460635 Terminal (12 Gauge) 5
439G 4460871 Socket, Female AR
439H 4460434 Plug, Male 15- Position 2
4460227 Pin AR
439I 3990010 Diode - 6 Amp (Not Shown) 2
FIGURE 7-3. HARNESS COMPONENTS INSTALLATION (WITH ADE SYSTEM) (SN 0300064432 TO
SN 0300069000)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
