JLG 800A_AJ Parts Manual - Manual (Page 163)

3120859 4-41
SECTION 4 PLATFORM
S
E
C
T
I
O
N
4
P
L
A
T
F
O
R
M
FIGURE 4-10. LOAD SENSING SYSTEM INSTALLATION (FRENCH SPEC) (PRIOR TO SN
0300067883)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
NOTE: THESE MACHINE SN’S ALSO EQUIPPED WITH
ADE SYSTEM: 0300062045, 0300062797, 0300063013,
0300063665, 0300063975, 0300064000-0300064017,
0300064390, 0300064392 & 0300064411. Ref
PLATFORM LOAD SENSING DEVICE INSTALLATION
OPTIONS (FRENCH SPEC): Ref
0258767 800A (PRIOR TO SN 0300058378) Ref D
0258768 800AJ (PRIOR TO SN 0300058378) Ref D
1 2901557 Load Sensing Assembly 1
1A 7020057 Display Unit - 12V DC. 1
1B 7020058 Converter (Junction Box) 1
1C 7020059 Load Cell 2
2 3570740 Plate, Spacer 2
3 0962180 Spacer, Load Cell 2
4 0641818 Bolt 1/2in-13NC x 2-1/4in 2
5 3311805 Locknut 1/2in-13NC 2
6 4751800 Flatwasher 1/2in 2
7 0641616 Bolt 3/8in-16NC x 2in 4
8 3311605 Locknut 3/8in-16NC 4
9 4751600 Flatwasher 3/8in 4
10 0641416 Bolt 1/4in-20NC x 2in 3
11 3311405 Locknut 1/4in-20NC 3
12 4751400 Flatwasher 1/4in 3
13 to 15 Not Used
16 1703801 Decal - Load Sensing Device Lights 1
17 3124025 Manual Supplement (Not Shown) 1
0259233 PLATFORM LOAD SENSING DEVICE INSTALLATION
(FRENCH SPEC) (SN 0300058378 TO SN 0300064432) Ref 4/C
101 2901811 Load Sensing Assembly 1
101A 3990109 Transducer, Pressure 1
101B 7023332 Card, Control 1
7023331 Fuse 1
7023333 Holder, Fuse 1
102 0701010 Bolt 10mm x 20mm 2
103 4812000 Flatwasher 10mm 2
104 1670900 Cover, Load Cell 1
105 0641407 Bolt 1/4in-20NC x 7/8in 4
106 4761400 Washer, Spring Lock 1/4in 4
107 3311401 Nut 1/4in-20NC 4
