3120859 3-19
SECTION 3 BOOM
S
E
C
T
I
O
N
3
B
O
O
M
FIGURE 3-5. ROTATOR ASSEMBLIES (FRONT ENTRY PLATFORM)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
ROTATOR ASSEMBLIES Ref
800A Ref
0060041 Actual Production Ref G
0060077 Recommended Replacement Ref B
800AJ Ref
0060031 Actual Production Ref I
1001103095 Recommended Replacement Kit (contains
0060074 rotator, upper pin, keeper shaft, keeper
shaft bolt & instruction sheet) Ref 1
Note: Before ordering parts, identify whether origi-
nal equipment rotator has been replaced with ser-
vice replacement. Service replacement rotator uses
spacer plate bolted on the top with 8 capscrews
(Not shown - located at item 2). Original equipment
rotator does not use spacer plate. Ref
1 See Note Housing/Ring Gear Assembly (Note: Not Available -
Purchase Complete Assembly.) 1
2 Shaft Weldment Options: 1
Use 7017177 0060041 & 0060031 Rotators (was p/n 7017117)
7017162 0060077 & 0060074 Rotators
See Note Plate, Spacer (Not Shown) (0060077 & 0060074
Rotators Only) (Note: Not Available for Purchase.) 1
3 Piston/Sleeve Options: 1
7017115 0060041 & 0060031 Rotators
7017163 0060077 & 0060074 Rotators
4 Cap, End Options: 1
Use 7017174 0060041 & 0060031 Rotators (was p/n 7017116)
7017164 0060077 & 0060074 Rotators
5 See Note Plug, Port (Note: Not Available for Purchase.) 6
6 Use 7017142 Plug 2
7 7017102 Tie-Rod/Locknut Assy 1
7017119 Bolt 1in-8NC x 11in 1
8 3272605 Locknut 1in-8NC AR
9 See Note Seal, Cap (Note: Use Item 25) 1
10 See Note Ring, Back-up (Cap) (Note: Use Item 25) 1
11 See Note Seal, Rod (Note: Use Item 25) 1
12 See Note Seal, Piston (Note: Use Item 25) 1
13 See Note Packing, Bearing (Note: Use Item 25) 2
14 See Note Bearing, Cap (Note: Use Item 26) 1
15 See Note Bearing, Shaft (Note: Use Item 26) 1
16 See Note Washer, Thrust (Note: Use Item 26) 2
17 Valve Assembly Options: 1
Use 7017183 0060041 & 0060031 Rotators (was p/n 7017101)
7017183 0060077 & 0060074 Rotators
17A Cartridge, Valve Options: 2
7011331 0060041 & 0060031 Rotators
7017193 0060077 & 0060074 Rotators
2900770 Seal Kit - 7011331 Valve 2
