JLG 800A_AJ Parts Manual User Manual
Page 103
3120859
3-9
SECTION 3 BOOM
S
E
C
T
I
O
N
3
B
O
O
M
102
0100011
Compound, Locking
AR
103
0641606
Bolt 3/8in-16NC x 3/4in
2
104
0641810
Bolt 1/2in-13NC x 1-1/4in
6
105
0681610
Bolt 3/8in-16NC x 1-1/4in (Grade 8)
4
106
0641820
Bolt 1/2in-13NC x 2-1/2in
4
107
3311805
Locknut 1/2in-13NC
4
108
3841340
Rod, Hose Loop
1
109
4711600
Flatwasher 3/8in Narrow
4
110
4711800
Flatwasher 1/2in Narrow
8
111
Support Weldment Options:
1
4844790
Australian Spec
4845682
CE Spec (Prior to SN 0300054596)
4846081
CE Spec (SN 0300054596 to SN 0300069000)
PLATFORM SUPPORT INSTALLATIONS (SIDE ENTRY
PLATFORM)
Ref
0272070
Australian Spec
Ref
B
0272071
CE Spec Only
Ref
C
201
0100011
Compound, Locking
AR
202
Bolt Options:
8
0641812
Australian Spec - Bolt 1/2in-13NC x 1-1/2in
0641822
CE Spec - Bolt 1/2in-13NC x 2-3/4in
203
0642682
Bolt 1in-8NC x 10-1/4in
1
204
Bolt Options:
8
0681608
Australian Spec - Bolt 3/8in-16NC x 1in
0681610
CE Spec - Bolt 3/8in-16NC x 1-1/4in
205
3272605
Locknut 1in-8NC
1
206
3311805
Locknut 1/2in-13NC
8
207
4846573
Support Weldment
1
208
4891600
Flatwasher 3/8in (Hardened)
8
209
4891800
Flatwasher 1/2in (Hardened)
8
210
4892600
Flatwasher 1in (Hardened)
1
FIGURE 3-2. BOOM AND CYLINDER INSTALLATION - 800AJ (CONTINUED)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
