3120859 4-1
S
E
C
T
I
O
N
4
P
L
A
T
F
O
R
M
SECTION 4 PLATFORM
TABLE OF CONTENTS
FIGURE DESCRIPTION PAGE
4-1 PLATFORM COMPONENTS INSTALLATION (FRONT ENTRY) . . . . . . . . . . . . . . . . . . . . . . . . 4-2
4-2 PLATFORM COMPONENTS INSTALLATION (SIDE ENTRY) . . . . . . . . . . . . . . . . . . . . . . . . . . 4-8
4-3 PLATFORM CONSOLE ASSEMBLY (PRIOR TO SN 0300064432). . . . . . . . . . . . . . . . . . . . . . 4-12
4-4 PLATFORM CONSOLE ASSEMBLIES (WITH ADE SYSTEM) (SN 0300064432
TO SN 0300069000) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-18
4-5 CONTROLLER ASSEMBLY (SWING AND LIFT) (PRIOR TO SN 0300064432) . . . . . . . . . . . 4-24
4-6 CONTROLLER ASSEMBLY (SWING AND LIFT) (WITH ADE SYSTEM)
(SN 0300064432 TO SN 0300069000) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-26
4-7 CONTROLLER ASSEMBLY (DRIVE AND STEER) (PRIOR TO SN 0300064432) . . . . . . . . . . 4-30
4-8 CONTROLLER ASSEMBLY (DRIVE AND STEER) (WITH ADE SYSTEM)
(SN 0300064432 TO SN 0300069000) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-32
4-9 SOFT TOUCH SYSTEM INSTALLATION (OPTIONAL) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-36
4-10 LOAD SENSING SYSTEM INSTALLATION (FRENCH SPEC) (PRIOR TO SN 0300067883) . 4-40
4-11 PLATFORM SUPPORT (LOAD SENSING) (SN 0300067883 TO SN 0300069000) . . . . . . . . . 4-44
