SECTION 6 - GENERAL SPECIFICATIONS AND OPERATOR MAINTENANCE
3121221 – JLG Lift – 6-15
223 FUNCTION PROBLEM - DRIVE & LIFT
ACTIVE TOGETHER The drive and lift inputs are closed simulta-
neously in platform mode. • Check drive/lift switch for visible damage.
Refer problem to a qualified JLG mechanic.
224 FUNCTION PROBLEM - STEER LEFT PER-
MANENTLY SELECTED The steer left switch was closed during
power-up in platform mode. • Check if the steer left switch is obstructed or jammed.
Refer problem to a qualified JLG mechanic.
225 FUNCTION PROBLEM - STEER RIGHT
PERMANENTLY SELECTED The steer right switch was closed during
power-up in platform mode. • Check if the steer right switch is obstructed or jammed.
Refer problem to a qualified JLG mechanic.
226 ACCELERATOR FAULTY - WIPER OUT OF
RANGE There is a problem with the joystick. • Center joystick and check to see if a power cycle will clear DTC.
Refer problem to a qualified JLG mechanic.
227 STEER SWITCHES FAULTY The steer left and steer right inputs were
closed simultaneously. • Check if the steer switches are damaged, obstructed or jammed.
Refer problem to a qualified JLG mechanic.
228 FUNCTION LOCKED OUT - ACCELERATOR
NOT CENTERED The joystick was not centered at power-up. • Release joystick and allow to center.
• Check if the joystick is obstructed or jammed.
Refer problem to a qualified JLG mechanic.
229 FUNCTION PROBLEM - TRIGGER PER-
MANENTLY CLOSED The trigger switch was closed during power-
up in platform mode. • Check if the trigger switch is obstructed or jammed.
Refer problem to a qualified JLG mechanic.
2210 TRIGGER CLOSED TOO LONG WHILE IN
NEUTRAL
The trigger switch was closed for more than
five seconds while the joystick was centered. • Check if the trigger switch is obstructed or jammed.
Refer problem to a qualified JLG mechanic.
2232 FUNCTION PROBLEM - DRIVE & LIFT
BOTH OPEN
The drive and lift inputs are both de-ener-
gized in platform mode. • Check if either function is active, if Yes;
Refer problem to a qualified JLG mechanic.
2-2 Platform Controls
DTC FAULT MESSAGE DESCRIPTION CHECK
