SECTION 2 - USER RESPONSIBILITIES, MACHINE PREPARATION AND INSPECTION

2-6

– JLG Lift –

3121221

3. With the platform in the transport (stowed) position.

a. Drive the machine on a grade, not to exceed the

rated gradeability, and stop to ensure the brakes
hold.

b. Check the tilt indicator light/alarm to ensure

proper operation. The light/alarm should be acti-
vated when tilted at or beyond the values in Table
2-2.

NOTE: When the tilt indicator warning is activated the following

functions are affected;

ANSI/CSA/AUS Spec. - Drive and Lift functions are dis-
abled, platform must be lowered (stowed) to drive out of
tilt condition.

CE Spec. - Drive and Lift function are NOT disabled.

Table 2-2. Tilt Cutout Settings

1230ES

Tilt Setting

(front to back)

Tilt Setting

(side to side)

ANSI/CSA

3°

1.5°

CE/AUS

3.4°
