SECTION 6 - GENERAL SPECIFICATIONS AND OPERATOR MAINTENANCE

3121221

– JLG Lift –

6-3

Platform Capacities

Dimensional Data

Table 6-2. Capacities

MODEL

ANSI/CSA

CE/AUST

(INDOOR ONLY)

Max.

Capacity

Max.

Persons

Max.

Capacity

Max. Persons

1230ES

500 lb.

230 kg

Table 6-3. Dimensions

DESCRIPTION

MODEL 1230ES

Platform Height - Elevated

12 ft.

3.66 m

Platform Height - Stowed

22 in.

56 cm

Working Height

18 ft.

5.48 m

Overall Stowed Machine Height

65.25 in.

166 cm

Rail Height (From platform floor)

43.8 in.

111.2 cm

Overall Machine Width

30 in.

76 cm

Overall Machine Length

53.5 in.

1.36 m

Platform Size - Length

49.4 in.

1.26 m

Platform Size - Width

27 in.

0.69 m

Wheelbase

40.75 in.

103.5 cm
