SECTION 6 - GENERAL SPECIFICATIONS AND OPERATOR MAINTENANCE
6-2 – JLG Lift – 3121221
6.1 OPERATING SPECIFICATIONS
Table 6-1. Operating Specification
DESCRIPTION MODEL 1230ES
PLATFORM
Maximum Platform Height 12 ft. (3.66 m)
DRIVING
Maximum Drive Speed Stowed
Elevated
3 mph (4.8 kph)
0.5 mph (0.8 kph)
Maximum Stowed Travel Grade (Gradeability)
(Reference Figure 4-12. on page 4-14)
25% (14°)
Maximum Stowed Travel Grade (Sideslope)
(Reference Figure 4-12. on page 4-14)
5°
Maximum Elevated Travel Grade (Gradeability) 3° - ANSI
3.4° - CE
Maximum Elevated Travel Grade (Sideslope) 1.5° - ANSI
3.4° - CE
Inside Turning Radius 4.4 in. (11.2 cm)
Outside Turning Radius 57.6 in. (1.46 m)
CHASSIS
Approximate Gross Machine Weight -
ANSI/CSA/CE/Australia 1740 lb. (790 kg)
Maximum Tire Load (per wheel) 880 lb. (400 kg)
Ground Bearing Pressure
123 PSI (8.7 kg/cm
2
)
Ground Clearance -
(pot hole protection system up)
(pot hole protection system down)
2.6 in (66 mm)
0.5 in (12.2 mm)
Maximum Operating Wind Speed ANSI/CSA - 28 mph
CE/AUST - 0 m/s -
Indoor Use Only
Maximum Horizontal Manual Side Force:
(Platform fully extended with Maximum load) ANSI/CSA -100 lb force - (445
Newtons)
CE/AUST - 200 Newtons - (45 lb
force)
Maximum Hydraulic Pressure 1600psi (110 bar)
Electrical System Voltage (DC) 24V
Table 6-1. Operating Specification (Continued)
DESCRIPTION MODEL 1230ES
